喷印对象
|
Printing objects
|
可在任何材料表面的任何位置喷印清晰牢固的文字标识
|
Print clear and firm characters and logos on any positions of any surfaces
|
喷印行数
|
Printing lines
|
一行至5行的信息(1-32点间任意设定)
|
One to fiv lines(1-32 arbitrary set point)
|
字符高度
|
Character height
|
0.8~25mm
|
0.8~20mm
|
喷印速度
|
Print speed
|
350米/分(5X6点)
|
350m/ min(single5×6)
|
喷印距离
|
Printing distance
|
1~150mm
|
1~150mm
|
墨点间距
|
Ink dot spacing
|
4~16点(可调)
|
4-16 point (Adjustable)
|
信息容量
|
Information capacity
|
高(1-40)点、宽(1-3000)列:
5x6点字符可编4000个(1条信息)
|
High(1-40)point and wide(1-3000)column:
5X6 point character can be compiled 4000(1 messages)
|
喷印格式
|
Printing Format
|
中英文、图文、产品批号、计数、生产日期、有效期、条邢码、二维码
|
Chinese and English,graphic,product batch number, count,production date, validity, Bar code, two-dimensional code
|
喷印字符
|
Jet printing character
|
阿拉伯数字、英文字母大小写及键盘的所有符号
|
Arabia numbers, letters and symbols
|
字符点阵
|
Charater dot matrix
|
5x5、7×5、7×7、10x7、12×12、16×8、16×12、16×16、24×16、32×24(高X宽)点
|
5x5、7×5、7×7、10x7、12×12、16×8、16×12、16×16、24×16、32×24
|
喷印汉字
|
Printed chinese characters
|
黑体
|
The font, bold, ita lics, official script, cursive
|
汉字点阵
|
Chinese dot matrix
|
8×8、8×12、12×12、16×16、24×16、32×24
|
8×8、8×12、12×12、16×16、24×16、32×24
|
图形绘画
|
Graphic drawing
|
图案可以通过本机直接绘制,也可以通过外部电脑使用其它绘图或照片处理软件制图,用墨白像素高度在32点以下)制成bmp格式文件,由U盘插入本系统直接打印
|
Patterns can be drawn directly from the machine, but also through the external computer Other drawing or photo proce ssing software; ink white pixels(height) Below 32 points, made of BMP format file, insert the U disk Direct print system
|
喷印方式
|
Print method
|
自动、光电同步定距,同步轮计米、一次光电检测喷印N次(N=1-97),外配编码同步器,可对物件做定距离喷印及不均匀传输带物件的喷印
|
Automatic, photoe lectric synchronous fixed distance, synchronous wheel meter meter, primary photoelectric detectionJet printing N times(N=1-97) with the code synchronizer can be fixed on the objectDistance coding and non-uniform transmission belt object printing
|
加宽加浓
|
Widening and thickening
|
喷印时,对某一特殊字符加高加粗
|
Spray printing, on a special character plus coarse
|
油墨种类
|
Ink types
|
黑、白、黄、红、蓝色,丁酮基/酒精/合基
|
black,white,yellow,red,blue,butanone base/alchol/mixed group.
|
通信接口
|
Communication interface
|
Rs232外接电脑直接实时喷印,可将U盘內存储卡插入本机,读入已编好的信息啧印
|
|
